- Item: Class-A amplifier - RHINO -
- Type: JLH1969
- Posted: 23 December 2012
- Builder: leopard
- Country: Sweden
- Comments: 2
- Rhino -
I know i already had a final version of my JLH1969, but after i got a pair of heatsinks i decided to push this old schematic a bit harder. Now it is working with the previous PCB board with some small modifications. It is dissipating 80W per channel and i get ca 12% of it at the output. Same 2SC2922 Sanken transistors at the output, Takman Carbon Film resistors, RIFA capacitors etc. The input cap is an old NOS russian military PIO K40Y-9 having 1uF in capacitance. Total weight is about 25Kg.
The sound is the same i had before i guess. What i noticed is that an amplifier became much more sensitive to the input capacitors. Changing it you can really feel the differences (the value remains the same).
The sound is the same i had before i guess. What i noticed is that an amplifier became much more sensitive to the input capacitors. Changing it you can really feel the differences (the value remains the same).
